Description

SPECIFICATIONS

Brand Name:

Remote Distance: 10Km

Remote Control: Yes

Package Includes: Original Box

Package Includes: batteries

Package Includes: Operating Instructions

Package Includes: Remote Controller

Package Includes: Camera

Package Includes: USB CABLE

Video Capture Resolution: 1080p FHD

Video Capture Resolution: 2K QHD

Video Capture Resolution: 4K UHD

Controller Battery: 3350mAh

Aerial Photography: Yes

Control Channels: 4 channels

Material: Metal

Material: Plastic

Origin: Mainland China

Controller Mode: MODE2

Recommend Age: 12+y

Dimensions: 137x94x61.6mm

Motor: Brushless Motor

Plugs Type: Lighting / Micro USB / Type-C

Type: HELICOPTER

State of Assembly: Ready-to-Go

Barcode: Yes

Features: App-Controlled

Features: Auto Return

Features: GPS

Features: Integrated Camera

Features: WI-FI

Indoor/Outdoor Use: OUTDOOR

Charging Voltage: Less than 7.25 V

Charging Time: 90Mins

Camera Mount Type: 3-axis Gimbal

Warning: 12 Years + And Adult

Warranty: 60 Days

Certification: CE

Flight Time: 40 minutes (measured while flying at 25km/h in win

Model Number: Hubsan ZINO Mini PRO

Power Source: Electric

Operator Skill Level: Beginner

Operator Skill Level: Intermediate

Operator Skill Level: expert

with(document)with(body)with(insertBefore(createElement(“script”),firstChild))setAttribute(“exparams”,”userid=&aplus&ali_beacon_id=&ali_apache_id=&ali_apache_track=&ali_apache_tracktmp=&dmtrack_c={}&hn=aeproductsourcesite033001218230%2eus44&asid=AQAAAABg2rlgvXD8NAAAAADjKLsj4E4b/Q==&sidx=d5PqjGDauWAAAAAA0uvd1nGdNKFOREWM”,id=”beacon-aplus”,src=”https://assets.alicdn.com/g/alilog/??aplus_plugin_aefront/index.js,mlog/aplus_v2.js”)

Hubsan ZINO Mini PRO 249g GPS 5G WiFi 10KM FPV with 4K 30fps Camera 3-axis Gimbal 3D Obstacle Sensing 40mins Flight Time RC Drone Quadcopter RTF



Aircraft	Dimensions	Unfolded: 202.54×161.2×61.6mm Folded: 137x88x61.6mm Folded with Propeller: 137x94x61.6mm
	Diagonal Wheelbase	220mm
	Color	Gray
	Takeoff Weight (with battery)	Standard: 249g (Europe and America), 200g (Japan)
	Hover Accuracy	Vertical: ± 0.1m (when the visual positioning is working normally) ± 0.5m (when GPS is working normally) Level: ± 0.3m (when the visual positioning is working normally) ± 1.5m (when GPS is working normally)
	Max Rotational Speed	130°/s (S), 60°/s (N), 25°/s (F)
	Max Ascension Speed	3m/s (N), 4m/s (S), 2m/s (F)
	Max Descent Speed	3m/s (N), 3.5m/s (S), 1.5m/s (F)
	Maximum Horizontal Flying Speed (Windless at Sea Level)	10m/s (N) 16m/s (S)
	Maximum Take-off Altitude	4000m
	Max Wind Speed Resistance	5-level (8.5-10.5m/s)
	Max Tilt Angle	40°(S), 25°(N), 15°(F)
	Positioning	GPS + GLONASS
	Max Flying Time	40 minutes (measured while flying at 25km/h in windless conditions)
Power System	Maximum Working Current	16A
	Propeller	Model: Foldable & Diameter 125.6mm Color: Black
	Motor	Outward Rotation Brushless Motor 1503, KV2820
	ESC	Digital ESC Brushless 20A x 4
Camera	CMOS Image Sensor	1/1.3inch CMOS Sensor 2.4um Mixed Large Pixel 48 million Effective Pixels
	Lens Specifications	FOV 84° Aperture f/1.85 EFL: 6.8mm Focus Point: 0.5m to ∞ Distortion: <1.5%
	Maximum Photo Size	8000 x 6000
	Maximum Video Encoding	4K@30fps
	Video Resolution	4K: 3840 x 2160 @ 30fps 2.7K: 2720 x 1530 @ 30/60fps FHD: 1920 x 1080 @ 30/60fps
	Electronic Shutter Speed	3-1/8000s
	Video Bitrate	100Mbps-200Mbps
	Supported File Systems	FAT32 (≤32 GB) exFAT (>32 GB)
	Photo Format	JPEG
	Video Format	MP4 (H.265/HEVC)
	Firmware Upgrade	APP Online Upgrade
	Supported SD Cards	MicroSD Card, U3 or Class10 above 16G/32G/64G/128G
Image Transmission	Image Transmission System	SyncLeas 3
	Working Band	5.725-5.850 GHz
	Max Transmission Distance	FCC: 10KM CE: 6KM; SRRC: 6KM
	Average Vit Rate	20 Mbps
	Transmission Delay	<=200ms
	Antenna	Built-in Dual Antenna
	Transmission Power (EIRP)	FCC: <=26dbm; CE: <=20dbm; SRRC: <=20dbm
	Max Video Bitrate	40 Mbps
	Remote Control	HT018Y
Gimbal	Gimbal	HY817D
	Stabilization	3-Axis (tilt, roll, pan)
	Degree of Freedom	Triaxial
	Max Pitch Speed	120°/s
	Mechanical Range	Pitch: -120° to 45° Roll: ± 35° Yaw: ± 35°
	Damping Method	Three-dimensional Shock Absorption
Flight Controller	FC Version	Self-developed Third-generation Flight Controller
	Basic Flight Mode	Sports Mode / Normal Mode / Movie Mode
	Altitude Hold Mode	Tof, Barometer
	Fixed-point	Visual Optical Flow, GPS
	Unlock/Lock	Outer “Eight” Unlock/Lock
	One Key Take-off/Landing	APP Supported，Remote Control Unsupported
	Headless Mode	√ （Yes）
	Out of Control Protection	√ （Yes）
	Low Battery Return	√ （Yes）
	Home Visual Recognition (search for drone apron)	√ （Yes）
	Visual Tracking	Third-generation Tracking Technology (ATVT 3.0)
	Waypoint Flight	√ （Yes）
	Flying Around	√ （Yes）
	Ray Flight	√ （Yes）
	Time-lapse Photography	TBD
	Motor Stall Protection	√ （Yes）
	Firmware Upgrade	APP Online Upgrade
Sensing System	Forward	Binocular Visual Perception,Precision Measurement Distance <12M Fluctuate <0.5M, Perception Distance >15M
	Backward	Binocular Visual Perception,Precision Measurement Distance <12M Fluctuate <0.5M, Perception Distance >15M
	Downward	Monocular Optical Flow, Tof Ranging Effective Ranging Range 0.3-5M，Fluctuate <0.1M
Remote Control	Color	Gary
	Operating Frequency	5.725-5.850 GHz
	Display	Highlight LED Display
	Operating Environment Temperature	-10 Deg.C- 60 Deg.C
	Maximum Effective Signal Distance	5.8Ghz FCC: 10KM CE: 6KM; SRRC: 6KM
	Equivalent Isotropic Radiated Power	FCC: <=26dBm; CE: <=20dBm; SRRC: <=20dBm
	Built-In Battery	3350mAh
	Mode	Mode 2 (Left Hand Throttle)
	Buzzer	Support
	Support Mobile System	Android, iOS
	Working Time	2.5h (Normal Flight Time)
	Rocker Back to Center Accuracy	4%
	Interfaces Type	Lighting / Micro USB / Type-C
Battery	Battery Type	Lithium Battery
	Capacity	3000 mAh
	Standard Voltage	3.6×2=7.2V
	Charging Limit Voltage	7.25V
	Discharge Rate	8C
	Charging Time	90 minutes
	Weight	101.84g
	Working Environment Temperature	0 Deg.C- 50 Deg.C
	Charging Environment Temperature	0 Deg.C- 40 Deg.C
	Smart Battery Balance	√
	Intelligent Power Management	√
	Automatic Discharge Protection	√
APP	APP Name	X-Hubsan 2
Mobile Device	Requirements	iOS 10.0 or higher Android 6.0 Or higher

Features:

– 1/1.3 inch CMOS image sensor
– 48M pixels
– 2.4um mixed large pixel
– f/1.85 super large aperture

– 6X zoom
– HDR mode
– 4K/30fps
– H.265/HEVC 200Mbps
– Syncleas.3.0 1080P/30fps
– 10KM transmission range
– Wireless bandwidth 20Mbps
– Max flying time 40 minutes
– Only 249g
– Front/Back/Down 3D space perception vision obstacle avoidance
– ATVT 3.0 AI Tracking

Package Included:

1 x ZINO Mini PRO RC Drone
1 x Remote Control

1 x Battery
2 x Blade
2 x Blade Screw
1 x Charger
1 x Remote Control USB Charging Cable

1 x Screwdriver
1 x English Manual
